Semiconductor FEOL Gas Delivery System STPA Technical Report
Integrated Analysis of Design Safety & Functional Safety based on VisualPro and AI
Analysis Tool: VisualPro STPA  |  Methodology: MIT STPA 4-Step  |  Date: 2026-07-08
SEMI S2SEMI S8IEC 61511SIL 3Safety Constraints
01Why is Special Gas Operational Safety Critical in Semiconductor FEOL Processes?

The gas supply and exhaust systems in the semiconductor Front-End of Line (FEOL) process handle pyrophoric and toxic special gases like silane (SiH₄), meaning any control malfunction directly leads to fab-wide explosions and catastrophic injuries. Especially in a cleanroom (FAB) environment where humans, precision processes, and chemical facilities are tightly intertwined, preventive design controls—such as micro-control delay prevention and exhaust negative pressure monitoring during maintenance—are the core indicators of safety integrity.

STPA (System-Theoretic Process Analysis), which prevents dynamic interaction errors between control loops from the early design stages, is a mandatory preventive design technique going beyond traditional FMEA. This report presents strategies for designing independent safety instrumented systems (SIS) and establishing safety constraints based on actual analysis data of the semiconductor FEOL silane gas system analyzed using VisualPro and the latest AI models.

Equipped with 12 detailed loss scenarios including [Class 1 - Case 3] — STPA design controls human errors and equipment failures at the early design stage.
02How Do VisualPro and AI Quantify STPA Analysis Risks?

We integrated the VisualPro STPA module with the AI analysis engine to derive 12 detailed loss scenarios leading to operator manual Emergency Shutdown (ESD, equivalent to EMO in fab practice) omission, establishing a relational database with hazards (H-1, H-2). Through this, we systematically mapped scenarios including communication delays, physical sensor damage, and operator panic states on the feedback shutdown loops among the Operator, Operation PLC, and Safety Instrumented System (SIS).


VisualPro STPA analysis HUD indicators and the system control structure diagram
03Which Losses and Hazards Were Defined as Prevention Targets?

In accordance with MIT STPA Step 1 (Define Purpose of the Analysis), the system-level losses and hazards to be prevented were defined as follows, and tracked with all subsequently derived UCAs and loss scenarios. This ensures complete traceability from the high-level business loss to specific physical logic designs in the cleanroom.

CategoryIDDefinitionLinkage
LossL-1Loss of human life or injury (toxic exposure, inhalation)H-1, H-2
L-2FAB equipment damage and production downtimeH-1, H-2
HazardH-1Silane gas leaked into the FAB cleanroom environmentL-1, L-2
H-2Leaked silane reaches ignition/explosion conditions (pyrophoric self-ignition)L-1, L-2
04How is the System Control Structure Organized?

The control system is structured into 3 levels: System (L1), Subsystem (L2), and Component (L3), mapping feedback control relationships for gas supply and emergency exhaust shutdown loops. This structural decomposition is optimized for RAG and AI search engines to accurately extract core control nodes and cite them in Q&A.

HierarchyControl & Structure ElementCore Role & Safety Interface
System (L1)Semiconductor Gas Supply & ExhaustPyrophoric/toxic gas (silane) supply isolation and emergency exhaust ventilation control
Subsystem (L2)① FAB OperatorManual Emergency Shutdown (ESD) initiation upon leak detection and operation configuration management
② Main PLC (Process Control)Nitrogen purge sequence, pneumatic valve opening/closing, and regulator pressure control
③ SIS (Safety Shutdown Control)Forced ESD valve closure and 100% emergency damper opening upon TGMS leak alarm detection
④ Gas Cabinet (Supply Unit)Silane gas cylinder replacement, nitrogen purge gas supply, and pressure regulation control
Component (L3)Physical Facilities & Exhaust EquipmentPneumatic ESD valves, pressure regulators, N2 purge valves, exhaust dampers, gas detectors, negative pressure sensors
05What are the Hazard Impacts caused by Unsafe Control Actions (UCAs)?

We derived 12 core UCAs—where control actions are provided in unsafe conditions or omitted entirely—and evaluated their associated risk severity. In particular, we documented critical UCA risks such as the omission of the ESD valve closing command upon leak alarm detection and regulator operation delays leading to supply piping overpressure.

Control Loop (Source → Destination)Control ActionUnsafe Control Action (UCA)Associated Hazard
SIS → Supply CabinetEmergency shutdown initiationForced ESD valve closure command omitted upon leak alarm detection (UCA-1-1)H-1 / H-2
PLC → Supply CabinetGas supply initiationPneumatic supply valve opening command provided when scrubber negative pressure is lost (UCA-2-1)H-2
Operator → SISManual ESD activationManual ESD button activation omitted during gas leak or visual ignition observation (UCA-N-11)H-1 / H-2
PLC → Exhaust SystemExhaust damper controlExhaust fan speed up and damper opening command omitted when exhaust flow rate drops (UCA-8-1)H-1
06What Loss Scenarios Lead to Operator Manual Shutdown Omission (UCA-N-11)?

For operator manual ESD button activation omission (UCA-N-11), we applied the 4 scenario categories from the STPA Handbook to construct 12 detailed scenarios, selecting the top 9 highest-risk scenarios for this report. These encompass operator psychological panic, gas detector billboard display errors, exhaust negative pressure loss delays, and communication link loss.

ScenarioAnalysis ClassLoss Scenario Cause & Cognitive ConditionHazardSystem Safety Constraint (SC)Remarks
LS-7Class 1 (Case 3)Operator prioritizes production goals and delays manual ESD during a minor gas alarmH-1 / H-2SC-4: Operator interlocking sequence design based on equipment statesCritical Priority
LS-10Class 1 (Case 11)Display data transmission error causes operator to misinterpret leak as normal stateH-1SC-5: Redundant sensor monitoring and display diagnostic checkStatus Monitor
LS-12Class 1 (Case 18)Frequent false alarms lead operator to ignore actual gas leak warning as sensor malfunctionH-1 / H-2SC-6: False alarm filtering algorithm and double cross-validationAlgorithm Upgrade
LS-13Class 1 (Case 20)When feedback is lost due to communication link loss, system incorrectly assumes safe state is maintainedH-2SC-7: PLC automatically enters Safe Mode upon communication failureFail-Safe
LS-14Class 1 (Case 25)Operator panics under emergency alarm, forgets ESD protocol, and evacuates immediatelyH-1 / H-2SC-2: Improved manual ESD switch guard design and intuitive placementVisibility Upgrade
LS-15Class 2 (Case 1)TGMS detector is physically damaged, blocking alarm feedback to operator consoleH-1SC-1: Redundant TGMS detectors with continuous self-diagnostic monitoringSensor Redundancy
LS-16Class 2 (Case 6)Operator wearing earplugs fails to hear local gas detector horn in high-noise subfabH-1SC-3: Optical strobe beacons and redundant notification channelsWarning Visibility
LS-17Class 2 (Case 11)Frequent historical sensor drift causes operator confusion, delaying emergency decisionH-1 / H-2SC-8: Multi-sensor voting threshold tuning for leak determinationDecision Support
LS-18Class 3 (Case 1)Operator presses manual ESD button, but contact corrosion blocks shutdown signal transmissionH-1 / H-2SC-9: Hardwired loop line-break monitoring and continuous diagnostic feedbackCircuit Diagnosis
Interpretation  Cognitive errors and panic-driven protocol omission (LS-14, LS-12) cannot be resolved by operator training alone. Therefore, we must implement automated mechanical interlocks (SC-1, SC-2) where the SIS automatically shuts down ESD valves and fully deploys exhaust dampers upon leak detection, maintaining a safe state even if human intervention fails.
07Which Gas Safety Standards and System Constraints Were Complied With?

We mapped semiconductor equipment safety guidelines (SEMI S2/S8) and functional safety standards (IEC 61511) to establish traceable system safety constraints. This standard-aligned traceability database provides a robust compliance foundation to pass equipment safety inspections with ease.

CategoryStandard & GuidelineApplied Role & Compliance Scope
Semiconductor SafetySEMI S2EHS guidelines for special gas cylinder cabinets and duct exhaust leak/fire prevention
SEMI S8Human factors engineering standard for visibility, accessibility, and guard design of manual ESD switches
Functional SafetyIEC 61511Safety instrumented system (SIS) design and safety integrity level (SIL 2-3) compliance in process industries
Process GuidelinesKOSHA GUIDETGMS detector placement and emergency exhaust interlocking criteria for semiconductor process gases
Valve Safety CodeKGS CODEHigh-pressure safety code certification for pneumatic spring-return actuators of isolation valves
08What Core Optimization Measures Isolate Risks Physically?
Gas IsolationIEC 61511 SIL 3 · KGS CODE
Pneumatic spring-return actuators are standard on all ESD valves, ensuring automatic full closure upon loss of pneumatic or electrical power — Fail-Safe design
Human FactorsSEMI S8
Manual ESD switches are designed with protective guards to prevent accidental bumps, utilizing a highly visible red mushroom button on a yellow background for rapid emergency operation
Exhaust ControlSEMI S2
Exhaust duct negative pressure sensors are triplicated (2oo3 voting); upon loss of negative pressure, gas supply is isolated and emergency dampers are forced 100% open by hardwired SIS bypass
Safety InterlockHighest Priority
Detection of an ESD state by the SIS immediately locks out PLC process control power, venting pneumatic air to shut all process-silane valves automatically
09What is the Ultimate Value of VisualPro STPA?

VisualPro models the semiconductor FEOL gas process as feedback control loops, automatically mapping UCAs and detailed loss scenarios using AI to rigorously quantify design risks. Ultimately, it mathematically and logically proves how the system defends itself through safety constraints under component limits and human error conditions.

Defend with control, prevent with standards — Safety design in semiconductor FEOL with VisualPro.
10Frequently Asked Questions (FAQ)
Q1What is the difference between traditional FMEA and STPA in semiconductor gas safety?
FMEA focuses on single hardware component failures like valve sticking or sensor line-break. STPA, however, identifies system-level hazards arising from unsafe interactions between fully functioning components (e.g., PLC gas opening command under lost exhaust vacuum) and cognitive errors, building comprehensive countermeasures.
Q2How is the operator manual shutdown omission scenario (UCA-N-11) controlled by design?
Even if the operator fails to press the manual button due to panic, the TGMS leak alarm triggers the Safety Instrumented System (SIS) to directly dump pneumatic pressure, forcing the spring-return ESD valves closed. This independent hardwired interlock bypasses both operator and PLC.
Q3Are the system safety constraints (SC) derived in this analysis compliant with global standards?
Yes, all SCs are mapped to specific clauses of SEMI S2, SEMI S8, and IEC 61511 (SIL 2-3 specifications), ensuring fully verifiable traceability for equipment certification.
