etc.[VisualPro Tech Insight] Intelligent MCP Connection Guide for Deepseek GUI(KUN) & VisualPro

01. VisualPro MCP Integration Overview & Key Values

Deepseek GUI(KUN) is a desktop AI assistant powered by the Deepseek API that connects directly to the VisualPro MCP Server through the Model Context Protocol (MCP) standard. Registration is completed by adding a single code block to the plugin configuration file (mcp.json).

02. Prerequisites & Required Environment

03. 5-Step Deepseek GUI(KUN) Integration Guide

STEP 1. Prepare the Deepseek GUI(KUN) App

Install the Deepseek GUI(KUN) app on your PC and launch it. A Deepseek API connection (API key) is required on first launch.

STEP 2. Edit the Plugin Configuration File (mcp.json)

Click Plugins → Manage to open the configuration file location, then open the mcp.json file with a text editor (e.g., Notepad), add the code below, and save it. If other server entries already exist, separate them with a comma (,).

💻 mcp.json

"VisualPro": {
  "command": "C:\\Program Files\\VWAY\\MCPServer\\VisualPro.McpServer.exe",
  "args": [],
  "enabled": true
}

STEP 3. Restart the Deepseek GUI(KUN) App

After completing the setup, fully quit and restart the Deepseek GUI(KUN) app. Configuration changes take effect only after a restart.

STEP 4. Verify MCP Registration

Check that the VisualPro MCP Server is registered correctly in Deepseek GUI(KUN). Click Plugins — when VisualPro is shown as Connected, the connection is ready.

STEP 5. Start VisualPro AI Conversational Analysis

With VisualPro running, freely instruct analyses in the Deepseek GUI(KUN) session using natural language such as 'Run FMEA failure mode analysis' or 'Verify Safety Mechanisms'.

04. Cautions & Notes

•  If mcp.json already contains other server entries, separate them with a comma (,). JSON path separators must be written as double backslashes (\\).

•  The VisualPro MCP Server is a local (stdio) executable that runs as a subprocess on your PC — no network access required. (This differs from remote MCP servers that require an HTTPS address.)

•  After editing the configuration file, fully quit and restart the Deepseek GUI(KUN) app for the changes to take effect.

•  VisualPro must be running before you start an analysis.
